Proprietary Subsea Gaskets

Flexiteck UK

Style: 330

Subsea operations in the oil and gas industry are done in the deep sea, at four thousand (4,000) to eight thousand (8,000) feet. The exploratory wells go even deeper than ten thousand (10,000) feet. The hydraulic pressure of such a setting is immense, and the demand for effective gaskets to prevent oil/ gas leakages from flanges is vital. Among all types of gaskets, AX gasket, VX gasket, and CX gasket are specified for subsea applications in offshore drilling manufacturing systems. Due to their special features, they suit well on wellhead equipment such as Blow out Preventers (BOP), and are generally called subsea gaskets.



Description



Star 21 International manufactures AX, VX, and CX gaskets by forging, heat treatments, and machining. They are light weighted, and they should ideally have a hardness 15-20HB lower than that of the mating flange surface.



Most importantly, we ensure an effective seal, by avoiding defects like scratches, knock-marks, and cracks on our subsea gaskets, and we always maintain the surface roughness not to exceed 0.8.



Materials



At Star 21 International, these gaskets are typically manufactured of stainless steel, and they include a range of different kinds of metal, namely: Soft Iron, Low Carbon Steel, SS410, SS304, SS316(L), SS347, F5, Copper, Aluminum, Inconel 800, 625, 600,825, Monel 400, Titanium, Nickel 20, Hastelloy C276, B3, Zoronium 702, etc.



Our gaskets are standardly subjected to silver plating as the coat, and it provides excellent dry film lubrication that lasts long, long term corrosion prevention, metal to metal seal, and the ability to pack out of microscopic irregularities and defects on the gasket seat due to the softness and malleability of silver.



What is special about our subsea gaskets?



Our gaskets are generally used in the oil and petrochemical, and offshore industries, where deep-sea explorations and productions are done under highly pressurized conditions. The specialty of our subsea gasket is that it can be applied on valves, pipe-work assemblies, and vessel joints, where flanges are subjected to high pressure and high temperature. As they are pressure-energized, these RTJ gaskets perform their best at high pressure.



As our gaskets are coated ‘in-house’, they provide excellent sealing consistently. The most important fact to remember when using our subsea gaskets is that each and every single gasket is manufactured with a unique product stamping to offer full identification and traceability to the customers.



Application of AX, VX, and CX Gasket



When applying subsea gaskets, it is important to be aware of their parts and other details. Our subsea gaskets are manufactured in both standard and non-standard sizes. This includes API 6A, API 17D, ASME B16.20, DIN 2693-67, JPI-7S-23-72, and other standards. In fact, the customers can often get their AX gaskets manufactured or crafted according to the purpose and the condition of the devices and machinery that they will be applied on.



Part numbers are constructed as follows:



T    -    NB    -    RMT    -    PR    -    RS    -    PC



T = TYPE (V, A, C)



NB = NOMINAL BORE (02, 03, 13, 16, 18)



RMT = RAW MATERIAL (LCS, 316, 825)



PR = RATING (05, 10, 15)



RS = NUMBER OF RESILIENT SEALS (00, 01, 02)



PC = COATING (00 = NONE, ZN = ZINC, AG = SILVER, XY = XYLAN, MS = Mo S2)










Sub-Sea Gaskets - Application Chart





Nominal

Material

Resilient

Maximum

Temp

Application





Size



Seals

Working

Range





Type

(inches)





Pressure

°C













(psi)

























SUBX18V1

VX

18¾

LCS

-

15,000

-20

+121

Wellhead Connector

SUBX18V2

VX

18¾

LCS

2

15,000

-20

+121

L.M.R.P Connector

SUBX18V2-1

VX

18¾

LCS

1

15,000

-20

+121

Test Stump

SUBX18V3

VX

18¾

SS316L

-

15,000

-20

+121



SUBX18V3X

VX

18¾

SS316L*

-

15,000

-20

+121



SUBX18V4

VX

18¾

SS316L

2

15,000

-20

+121



SUBX18V4-1

VX

18¾

SS316L

1

15,000

-20

+121



SUBX18V5

VX

18¾

INCONEL

-

15,000

-29

+232

Wellhead Connector

SUBX18V6

VX

18¾

INCONEL

2

15,000

-29

+232

L.M.R.P. Conector

SUBX18V6-1

VX

18¾

INCONEL

1

15,000

-29

+232

HTHP Applications

SUBX16V1

VX

16¾

LCS

-

15,000

-20

+121

Wellhead Connector

SUBX16V2

VX

16¾

LCS

2

15,000

-20

+121

L.M.R.P. Connector

SUBX16V2-1

VX

16¾

LCS

1

15,000

-20

+121

Test Stump

SUBX16V3

VX

16¾

SS316L

-

15,000

-20

+121



SUBX16V4

VX

16¾

SS316L

2

15,000

-20

+121



SUBX16V4-1

VX

16¾

SS316L

1

15,000

-20

+121



SUBX16V5

VX

16¾

INCONEL

-

15,000

-29

+232

Wellhead Connector

SUBX16V6

VX

16¾

INCONEL

2

15,000

-29

+232

 L.M.R.P. Connector

SUBX16V6-1

VX

16¾

INCONEL

1

15,000

-29

+232

HTHP Applications

SUBX13V1

VX

13⅝

LCS

-

10,000

-20

+121

Wellhead Connector

SUBX13V2

VX

13⅝

LCS

2

10,000

-20

+121

L.M.R.P.Connector

SUBX13V2-1

VX

13⅝

LCS

1

10,000

-20

+121

Test Stump

SUBX13V3

VX

13⅝

SS316L

-

10,000

-20

+121



SUBX13V4

VX

13⅝

SS316L

2

10,000

-20

+121



SUBX13V4-1

VX

13⅝

SS316L

1

10,000

-20

+121



SUBX18A1

AX

18¾

LCS

-

15,000

-20

+121



SUBX18A2

AX

18¾

LCS

2

15,000

-20

+121



SUBX18A2-1

AX

18¾

LCS

1

15,000

-20

+121



SUBX18A3

AX

18¾

SS316L

-

15,000

-20

+121



SUBX18A3X

AX

18¾

SS316L*

-

15,000

-20

+121



SUBX18A4

AX

18¾

SS316L

2

15,000

-20

+121



SUBX18A4-1

AX

18¾

SS316L

1

15,000

-20

+121



SUBX18A5

AX

18¾

INCONEL

-

15,000

-29

+232

Wellhead Connector

SUBX18A6

AX

18¾

INCONEL

2

15,000

-29

+232

L.M.R.P.Connector

SUBX18A6-1

AX

18¾

INCONEL

1

15,000

-29

+232

HTHP Applications

SUBX16A1

AX

16¾

LCS

-

10,000

-20

+121

Wellhead connector

SUBX16A2

AX

16¾

LCS

2

10,000

-20

+121

L.M.R.P. Connector

SUBX16A2-1

AX

16¾

LCS

1

10,000

-20

+121

Test Stump

SUBX16A3

AX

16¾

SS316L

-

10,000

-20

+121



SUBX16A4

AX

16¾

SS316L

2

10,000

-20

+121



SUBX16A4-1

AX

16¾

SS316L

1

10,000

-20

+121



SUBX13A1

AX

13⅝

LCS

-

10,000

-20

+121



SUBX13A2

AX

13⅝

LCS

2

10,000

-20

+121



SUBX13A2-1

AX

13⅝

LCS

1

10,000

-20

+121



SUBX13A3

AX

13⅝

SS316L

-

10,000

-20

+121



SUBX13A4

AX

13⅝

SS316L

2

10,000

-20

+121



SUBX13A4-1

AX

13⅝

SS316L

1

10,000

-20

+121



SUBX13A1-5K

AX

13⅝

LCS

-

5000

-20

+121



SUBX13A3-5K

AX

13⅝

SS316L

-

5000

-20

+121



SUBX13A4-5K

AX

13⅝

SS316L

2

5000

-20

+121



SUBX3A1

AX

3⅛  3 1/16

LCS

-

15,000

-20

+121

Choke & Kill Connections

SUBX3A3

AX

3⅛  3 1/16

SS316L

-

15,000

-20

+121

Valves

SUBX3A4

AX

3⅛  3 1/16

SS316L

2

15,000

-20

+121



SUBX3A1-5K

AX

3⅛  3 1/16

LCS

-

5000

-20

+121



SUBX3A3-5K

AX

3⅛  3 1/16

SS316L

-

5000

-20

+121



SUBX2A1

AX

2 9/16

LCS

-

15,000

-20

+121



SUBX2A3

AX

2 9/16

SS316L

-

15,000

-20

+121



SUBX18C1

CX

18¾

LCS

-

15,000

-20

+121

B.O.P. Stack

SUBX18C3

CX

18¾

SS316L

-

15,000

-20

+121



SUBX18C4

CX

18¾

SS316L

2

15,000

-20

+121



SUBX18C5

CX

18¾

INCONEL

-

15,000

-29

+232

B.O.P. Stack / HTHP

SUBX18C7

CX

18¾

SS316L**



15,000

-20

+121

B.O.P.Stack

SUBX18C9

CX

18¾

SS316L***



15,000

-20

+121





















*  Xylan Coated    ** 160-180BHN    *** 150-170BHN
